FTTH fiber optic cable skin line in the design of the full consideration of the process of entry into the home of a variety of mechanical challenges: reinforcing core using high-modulus FRP materials, can withstand 100N instantaneous tension, easy to deal with the hanging between the floor of the laying; at the same time, the fiber optic cable can withstand repeated bending (bending radius of ≥ 15mm is still maintained when the performance of the stability of the performance), even if crossing the gap between the door and window, around the beams and columns when the accidental extrusion, but will not affect the light! signal transmission. This toughness allows installers not to worry too much about the complexity of the wiring path, significantly reducing the difficulty of construction.
Product Features
1. Double-sheath anti-interference structure, isolating electromagnetic interference: wrapping a layer of aluminum foil shielding in the outer layer of the optical fiber, and then covering the high-density polyethylene sheath, forming a double anti-electromagnetic interference barrier. This structure can effectively block the electromagnetic signal interference generated by refrigerators, microwave ovens and other electrical appliances in the home, so that the optical signal transmission BER is reduced to less than 10-¹², to ensure the stability of the signal in online classes, telecommuting and other scenarios.
2. Self-adhesive laying design, simplify the installation process: the back of the fiber optic cable comes with removable high-strength double-sided tape, tear off the release paper can be directly pasted on the wall, corners and other locations, without the need to punch holes for fixing. Peel strength ≥ 5N/cm after pasting, can be maintained at room temperature for 10 years without falling off, especially suitable for rental users or families who do not want to destroy the wall.
3. Resistant to high and low temperature fiber optic paste filling, adapt to extreme climate: fiber optic cable filled with specially formulated fiber optic paste, in - 40 ℃ does not solidify, 80 ℃ does not flow, can always maintain the buffer protection of optical fiber. Even in the winter in the northern cold region or in the southern heat of the penthouse, it can avoid micro-cracks in the optical fiber due to drastic changes in temperature, ensuring that the signal transmission is not affected by the climate.
Product Advantages
1. Enhance the purity of signal transmission and reduce data loss: The double-sheath anti-interference structure allows the home network to maintain a stable gigabit rate when multiple appliances are running at the same time, reduces the video conferencing lag rate by 40%, and reduces the error rate of file transmission by 50%, providing reliable support for highly demanding network applications.
2. Reduce the dependence of installation on the environment, broaden the applicable population: self-adhesive design so that the installation does not require professional tools and construction experience, the user can complete the simple wiring, not only to save the installation costs, but also according to the furniture placed in the flexible adjustment of the line position, to meet the needs of personalized home layout.
3. Enhance product climate adaptability, expanding market coverage: high and low temperature characteristics of fiber optic cables in the Northeast, Northwest and other cold regions and Hainan, Yunnan and other high-temperature and high humidity can work stably, without the need to customize the product for different climatic zones, reducing the complexity of production and inventory manufacturers, and enhance the speed of response to the market.
Specification
|
|
Specification
|
|
Fiber count
|
1/2/4F
|
|
Fiber
|
Out diameter(±5μm)
|
250
|
|
|
Self supporting element
|
1.0mm Steel wire
|
|
Tensile element
|
2*0.4mm Steel wires
|
|
Sheath material
|
LSZH
|
|
Color
|
Black
|
|
Out diameter
|
5.1(±0.2)*2.0(±0.1) mm
|
|
Cable weight(kg/km)
|
22
|
