FTTH fiber optic cable skin line in the design of the full consideration of the process of entry into the home of a variety of mechanical challenges: reinforcing core using high-modulus FRP materials, can withstand 100N instantaneous tension, easy to deal with the hanging between the floor of the laying; at the same time, the fiber optic cable can withstand repeated bending (bending radius of ≥ 15mm is still maintained when the performance of the stability of the performance), even if crossing the gap between the door and window, around the beams and columns when the accidental extrusion, but will not affect the light! signal transmission. This toughness allows installers not to worry too much about the complexity of the wiring path, significantly reducing the difficulty of construction.
Product Features
1. Wear-resistant and scratch-resistant sheath to cope with daily wear and tear: special polyolefin material is used to make the sheath, the surface hardness reaches Shore D75 or above, and there is no obvious scratch after 5,000 times of friction test. For frequent walking in the family, furniture moving and other scenes, it can effectively resist the friction of the soles of shoes, tables and chairs, avoiding the sheath breakage to expose the optical fiber, and prolonging the actual service life of the optical cable.
2. Compatible with intelligent terminal interfaces, support for multi-device linkage: the end connector of the fiber optic cable is optimized and can be directly docked with the interfaces of intelligent optical cats, home gateways and other devices without additional transfer. At the same time, its transmission bandwidth can meet the demand for simultaneous networking of multiple devices such as smart door locks, security cameras, smart speakers, etc., providing stable high-speed network support for the smart home system.
3. Low-smoke and halogen-free environmental protection certification, in line with health standards: not only does the indoor section sheath use low-smoke and halogen-free materials, the entire production process also strictly follows the environmental protection requirements, and has passed the international authority of the SGS environmental protection test. When burning, the smoke concentration is low and no toxic gas is released, which is in line with the pursuit of healthy living environment for modern families, especially suitable for families with the elderly and children.
Product Advantages
1. Reduce the loss of daily use, reduce the frequency of replacement: wear-resistant and scratch-resistant sheath makes the fiber optic cable not easy to be damaged in the daily use of the family, and the average replacement cycle has been extended to more than 8 years, which reduces the number of replacement times by 30% compared with the ordinary fiber optic cables, and saves the user's maintenance costs and time.
2. Simplify the smart home networking, improve user experience: compatible with the characteristics of the smart terminal interface, so that users do not need to worry about the connection between the fiber optic cable and smart devices, easy to realize multi-device linkage. The stable transmission of the network also ensures the response speed of smart devices, which improves the overall experience of the smart home system.
3. In line with the concept of healthy living, enhance product competitiveness: low-smoke halogen-free environmental certification makes the product more attractive in the market, to meet the consumer's preference for healthy, environmentally friendly products. For real estate developers and home improvement companies, choosing this fiber optic cable can also enhance the quality and added value of the house.
Specification
|
|
Specification
|
|
Fiber count
|
1/2/4F
|
|
Fiber
|
Out diameter(±5μm)
|
250
|
|
|
Self supporting element
|
1.0mm Steel wire
|
|
Tensile element
|
2*0.4mm Steel wires
|
|
Sheath material
|
LSZH
|
|
Color
|
Black
|
|
Out diameter
|
5.1(±0.2)*2.0(±0.1) mm
|
|
Cable weight(kg/km)
|
22
|
